Tram TR79ML Power Supply For TR50 Lavalier Mics With A Mini 5pin Female XLR (TA5F)


Search For:   Lavalier Mics      Accessories

Click To Show Larger Image
Item#
TR79ML
Description
Power Supply For TR50 Lavalier Mics With A Mini 5pin Female XLR (TA5F) Connector & Wired For Lectrosonics Wireless Systems, Negative Bias, Uses 1.5VDC Button Cell Battery
Manufacture
Tram
TR79ML
Price
List Price:$160.00
Our Price:$154.00
Accepting Orders
12 to 15 business days
Return Classification

  • Product Notes
Powers Lavalier Mics With A TA5F And Outputs Audio Through A Standard 3pin XLR Male Connector.

Requires A 1.5VDC Button Cell Battery For Operation. Will Not Operate Via Phantom Power. For A Power Supply That Will Operate Via 12-48VDC Phantom Power You Can Special Order #Tr79ml+


How Can You Tell The Difference Between A Positive Or Negative Bias Power Supply?
• Older Versions:
• Positive Bias: Have A Plus [+] Sign (Usually Red) On The Plastic End Cap (The Color
Of The 3pin XLR Male Will Be Green)
• Negative Bias: No Distinct Markings (The Color Of The 3pin XLR Male Will Be Green)
• Newer Versions:
• Positive Bias: The Color Of The 3pin XLR Male Insert Is Black
• Negative Bias: The Color Of The 3pin XLR Male Insert Is Green


----------------------------------------
Features
----------------------------------------
• Tube Style Power Supply For Tram TR50 Mic
• Battery: Eveready #357 (Sr44w/313/ Mallory Rm675)
• Balanced Output On 3pin Male XLR Connector
• Size: 18mm X 85mm
• Output Impedance: 250 Ohm
